Specification
| LED Type | 160 × RGB 3-in-1 LEDs |
|---|---|
| LED Lifespan | >50,000 hours |
| Pixel Configuration | 4 × 40 pixels |
| Beam Angle | 125° |
| LED Pitch (Spacing) | 20 mm |
| Data Connection | 2 × Ethernet (RJ45) connectors for data source and auxiliary driver link |
| Linking Function | Each LED (160 pcs) can be independently controlled; RGB mixing system; configurable and software updatable via web-based network server |
| Control Modes | DMX512, Art-Net, Kling-Net, standalone, master/slave |
| Channel Modes | 8 / 480 channels |
| Optional Power | 50 W |
| Ingress Protection | IP20 |
