| Input Voltage |
AC110–240V,50/60Hz |
| Power Consumption |
300W |
| Light Source |
200W LED, 9000K color temperature, 50,000 hours lifespan |
| Pan / Tilt Motors |
Three-phase motors, powerful output, smooth and ultra-quiet operation |
| Pan / Tilt |
Pan 540°, Tilt 270°, 16-bit resolution for precise positioning |
| ZoomAngle |
9–42° |
| Dimming System |
Linear dimming 0–100% |
| Color Wheel |
Open + 9 colors |
| MetalGobo Wheel |
9 fixed metal gobos + open, with flowing and gobo shake effects |
| GlassGobo Wheel |
7 glass gobos + open, with gobo rotation, flowing and shake effects |
| Prism System |
1 triangular prism, adjustable rotation angle, maximum beam spread up to 80° |
| Frost System |
1 independent frost effect for soft and natural beam output |
| HighSpeedStrobe |
0–20Hz ultra-high-speed strobe |
| Display |
LED display with button control |
| ControlSystem |
DMX512 (international standard), 17 channels, RDM function supported |
| Control Modes |
Auto, Sound, DMX512 |
| Cooling System |
Aviation-grade aluminum heat sink with 4 silent fans, built-in temperature control system with automatic fan speed adjustment |
| IP Rating |
IP20, operating temperature -25°C to 45°C |
| Housing Material |
Flame-retardant high-temperature resistant plastic combined with high-strength alloy materials |
