| Voltage |
24V DC |
| Power |
13W |
| Light Source |
40 × high-brightness SMD5050 LEDs |
| Beam Angle |
120° |
| Luminous Intensity |
20 LUX at 1 meter |
| Color |
RGB |
| Pixel Matrix |
40 × 1 |
| Control Protocols |
DMX, Art-Net |
| Art-Net Channels |
120 |
| Housing |
Metal + plastic, matte black |
| Dimensions |
1000 × 35 × 100 mm |
| Weight |
1.6 kg |
| Controller |
| Power Supply |
AC 100–240V, 50/60Hz |
| Maximum Power Consumption |
320W |
| Control Protocols |
Art-Net, Kling-Net, DMX |
| Features |
Full digital control with front panel and LED display; automatic self-test even without a console |
| Control Output |
RJ45 connector |
| Data Connections |
Two Ethernet (RJ45) connectors for data source and auxiliary driver link |
| Universes |
4 output ports |
| Channels per Universe |
480 |
| Housing |
Steel |
| Protection |
IP20 |
